**How to Calculate the Right Air Conditioner Size for Your Home**

Additional Factors to Consider

✔️ Number of Windows & Sun Exposure
Rooms that receive direct sunlight require a larger air conditioner capacity.

✔️ Number of Occupants
More people → more heat → higher HP required.

✔️ Electrical Equipment in the Room
TVs, computers, and lighting generate additional heat.

✔️ Ceiling Height
Higher ceilings require greater cooling capacity.

Simple Calculation Example

A room sized 200 sqft:

200 ÷ 400 = 0.5

Recommended: 1.5 HP (for comfortable and long-lasting performance)

Effects of Choosing the Wrong Air Conditioner Size

❌ Air conditioner too small → slow cooling, higher electricity bill
❌ Air conditioner too large → frequent on/off, energy wastage
❌ Unstable performance
❌ Shorter air conditioner lifespan

Conclusion

Choosing the right air conditioner size will:
✔️ Save on electricity bills
✔️ Provide even and consistent cooling
✔️ Extend the lifespan of the air conditioner
✔️ Avoid unnecessary repair costs

If in doubt, seek advice from an experienced electrical or air conditioning contractor.

🔧 Need Professional Advice?

We provide:

Air conditioner size selection advice

Air conditioner-related wiring inspections

Registered electrical & air conditioning services

👉 Contact us for consultation

The capacity of split unit air conditioners is usually measured in HP (Horse Power). Common capacities available in the market are 1HP, 1.5HP, 2HP, 2.5HP, and 3HP.

VERSION 1

This calculation assumes the room is occupied by 2 people, has a 3-meter ceiling height, uncovered windows, and electrical equipment (including lighting) not exceeding 100W.

Air conditioner capacity = room area × 60 / 9000

required (length × width)

where:

room area = length × width (in square units)

Example:

A room measuring 16' × 20'. The air conditioner capacity calculation is:

room area = 16 × 20 = 320 square feet

air conditioner capacity = room area × 60 / 9000

= 320 × 60 / 9000 = 2.13 HP

Therefore, the suitable air conditioner capacity is 2.5 HP.

VERSION 2

Step 1

Calculate the room volume:
length (ft) × width (ft) × height (ft) = V ft³

Step 2

Multiply the volume by 6:

C1 = V × 6

Step 3

Estimate the number of people (P) using the room. Each person produces approximately 500 BTU/hour of body heat during normal daily activities.

C2 = P × 500 BTU/hour

Step 4

Add both values:

C1 + C2 = C (BTU/hour)

EXAMPLE

A room measuring 16' × 20' with a height of 9.8 ft (3 meters) and occupied by 2 people:

V = length × width × height

= 16 × 20 × 9.8 = 3136

C1 = V × 6

= 3136 × 6 = 18,816

C2 = P × 500 BTU/hour

= 2 × 500 = 1,000

C1 + C2 = C

= 18,816 + 1,000 = 19,816 BTU/hour
(within the range of 16,000 – 20,000 BTU/hour), equivalent to 2.0 HP

Reference

1 HP : 9,000 – 10,000 BTU/hour

1.5 HP : 12,000 – 15,000 BTU/hour

2 HP : 16,000 – 20,000 BTU/hour

2.5 HP : 22,000 – 27,000 BTU/hour

Therefore, the suitable air conditioner capacity is 2.0 HP.
